Fire Doors

Fire Protection/Proof Doors

The core purpose of fire rated door is to prevent the spread of fire & smoke. These doors are designed and used to slow down the prevention and spread of fire and smoke in commercial and household buildings.

The fire protection doors are commonly installed in commercial buildings, Offices, residential structures, and especially in public buildings.

The Mechatronix MEX fire doors are designed to prevent & spread the fire & smoke and withhold in high temperature. These doors are based on the world authentic standards of fire Rating. Mechatronix is the professional locally manufacturer of commercial Steel Fire proof doors.

• Rockwool, Ceramic Wool
• Honey Comb Panel, Air Chamber, Vacuum Chamber
• Panic Bar, Push Bar, Trim Lock
• Optional Door Automation/ Motorization

fire-rated-doors-mechatronix

Types Of Available Fire Rated Doors

single leaf fire rated door

Single Leaf

Single leaf Fire protection doors are fabricated to be installed in commercial areas. The standard size for single leaf is 3×7 ft. & 4×8 ft. The door optional accessories include Panic bar, door handle, Lock, Hinges etc.

double leaf fire door

Double Leaf

The double leaf Fire rated doors are installed in industrial facilities, towers, Health care centers etc. The accessories are vertical or horizontal panic bars, Vision panels, optional louvers etc. The door size is to be as requirements.

local made fire door

Locally Fabricated

MEX Locally Fabricated steel doors are fire proof & fire resistant. The core of the Fire door is Mineral Rockwool, Honeycomb, Ceramic wool etc. The door finishings are painted or as per customer specified requirements.

Product Description

Mex fire proof doors are designed, manufactured and tested by professional engineers and industry experts.

Mechatronix flame gates are fabricated to be installed in new and existing compartments areas that provides allowing time for occupants to escape. Steel fire gates are usually used in shopping complexes, offices, factories and residential apartments.

Product Specifications:

  • Mechatrnix Provides Full Range of sizes
    High Quality Stainless steel Hinges
  • High Quality Stainless Steel Handle
  • Door Leaf with High quality fire resistance door core
  • Choice of frames: wooden internal (standard), wooden embracing, steel frames (optional)
  • Mechatronix Provides wide range for finish & colors
  • Wide range of Accessories and Hardware Available
fire proof doors
Door Leaf Material 20 Gauge Mild Steel
Door Leaf Sheet G1 0.9mm thick sheet
Door Thickness 1.5 inches (Min)
Internal Insulator Hard Honeycomb Core, Rock Mineral Wool, Ceramic Wool
Surface Finish Painted / Customer Choice
Door Frame depth Normal Width of the frame: 115mm – 240mm
Door Frame Material 16 Gauge Mild Steel
Anchors Different Anchors, such as adjustable vertical anchor, Tee anchor, wire anchor, floor base anchor and etc.
Frame Type Reinforced core frame with stiffeners and filled with Ceramic/Rock
Open & Closure Data Turn or slide, in or out, left or right
Fire Resistance 30 – 45 – 60 – 90 – 120 minutes
Certificates & Labels UL Certified Label
Vision Panel With or without as requested
Louver With or without as requested
Accessories Lock, Handle, hinges, door closer, panic bar, Smoke Seals, and other as requested

Other Features:

Standards & Certifications:

– Standard for Safety for Fire Tests of Door Assemblies, ANSI/UL10B

– Positive Pressure Fire Test of Door Assemblies, ANSI/UL10C

– Standard Method for Fire Tests of Door Assemblies, CAN/ULC-S104-15

Fire Door Applications:

– High Impact Applications

– Utility buildings

– Residential Applications

– Interior Applications

– Education Centers & Embassies

– Commercial towers

– Health centers etc.

Door Accessories (Optional):
  • Heavy duty ball bearing Steel Hinges
  • All doors with self-closing and self-latching Fire Rated / Certified hardware
  • Smoke Seals to control fire and smoke spread

For more Details & technical Specifications download our MEX fire proof doors brochure.

Why Choose This Product!

Our fire rated door are designed and crafted to bear extensive fire heat for premium protection. Specially made from MS sheet pans, ceramics, honey comb panel with extra protection of epoxy and enamel coatings.

We strive for the best solution and to make fire gates more sophisticated and modernize, we deliver automated doors (operated electronically) that help to improve the security and appliance efficiency.

If you are worried about the build protection of the door, we are proud to present such special doors, that are not only heat proof but bulit and strike proof as well. These doors play a vital role for your security needs.

Mechatronics is always 1 step ahead to fulfill your security requirements. We provide you with most advance, modern and solid locking system in fire door, that keep safety at first and simply opened in emergency.
